• High Efficiency (Up to 93.5%)
  • Constant Voltage Output
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: OVP, OCP, SCP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

59,400 hours @ Case Temperature 60°C

Dimensions

Inches (L x W x H)
8.82 x 3.54 x 1.46

Millimeters (L x W x H)
224 x 90 x 37

Certifications

Output Voltage Input Voltage Range Output Current Range Max. Output Power Model Number
12 V

90 ~ 305 Vac

 0 ~ 18.33 A 220 W EUV-250S012SV
24 V 0 ~ 10.41 A

250 W

 EUV-250S024SV
28 V 0 ~ 8.93 A EUV-250S028SV
36 V 0 ~ 6.94 A EUV-250S036SV
42 V 0 ~ 5.95 A EUV-250S042SV
48 V 0 ~ 5.2 A EUV-250S048SV
54 V 0 ~ 4.62 EUV-250S054SV
File Name
LED Driver Installation Instructions (Updated March 2015)
Download
LED Driver Installation Guideline (Updated September 2018)
Download
