FEATURES

  • Low THD, 10% Max up to 240Vac
  • Compact Metal Case with Excellent Thermal Performance
  • Input Surge Protection: DM 4kV, CM 6kV
  • High Reliability & Long Lifetime: 80,000 hrs. at 70C Case Temperature
  • Suitable for Class I Luminaires
  • IUVP & IOVP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

80,000 hours @ Case Temperature 75°C

Dimensions

Inches (L x W x H)
3.15 x 2.52 x 1.26

Millimeters (L x W x H)
80 x 64 x 32

Certifications

Independent Gear Logo

Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
500 mA 90 ~ 305 Vac 32 – 64 Vdc 32W EUC-035S070SVM0004
700 mA 25 – 50 Vdc 35W EUC-035S070SVM
860 mA 20 – 41 Vdc EUC-035S105SVM0004
1050 mA 18 – 33 Vdc EUC-035S105SVM
Note: Models listed are not all-inclusive. For additional models please contact our sales department.

Notes:
(1) Certified input voltage range: 120-240Vac.
(2) Measured at 100% load and 220 Vac input.
(3) SELV output, certified to BIS.
(4) For BIS models please click here see the: BIS Models List
