- No Afterglow
- Hot-plugging Protection
- Parallel LED Protection
- Ultra High Efficiency (Up to 98.0%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
- INV Digital Dimming, UART Based Communication Protocol
- Adjustable Dimming Curve
- Dim-to-Off with Standby Power ≤ 0.5W
- Minimum Dimming Level with 5% or 10% Selectable
- Hold Time Adjustable
- Fade Time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
120,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
12.17 × 3.54 × 1.71
Millimeters (L x W x H)
309 × 90 × 43.5
Certifications
| Adjustable Output Current Range(mA) | Full-Power Current Range(mA) | Default Output Current(mA) | Output Voltage Range(Vdc) | Max. Output Power(W) | Typical Efficiency | Typical Power Factor | Model Number | |
|---|---|---|---|---|---|---|---|---|
| 200Vac | 480Vac | |||||||
| 200-4000 | 2000-4000 | 2000 | 150-500 | 1000 | 98.0% | 0.99 | 0.96 | NFL-1K0S400MT |
|
