Features
- Compact Metal Case with Excellent Thermal Performance
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with T4T(Tuner4TRONIC)
- Isolated 1(0)-5V/1(0)-10V/PWM/Resistor/AstroDIM(Timer) Dimmable
- Dim-to-Off with Standby Power ≤ 0.5 W
- Adjustable Dimming Curve
- Always-on Auxiliary Power: 12Vdc, 100mA on Specific Models
- End-of-Life Indicator
- Override Dimming
- Constant Lumen
- Input Surge Protection: DM 6kV, CM 6kV
- All-Around Protection: OTP, OVP, SCP
- Class 2 & SELV Output
- 5 Years Warranty
Application
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- Suitable for Luminaires with Protection Class I
- Suitable for Luminaires with Protection Class I and II on Specific Models
Life Time
120,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.74 x 2.52 x 1.26
Millimeters (L x W x H)
95 x 64 x 32
Certifications
Models
| Adjustable Output Current Range (mA) | Full Power Current Range (mA) | Default Output Current (mA) | Nominal Output Voltage Range (Vdc) | Maximum Output Power (W) | Typical Efficiency | Power Factor λ 120Vac |
Power Factor λ 230Vac |
Product Name |
|---|---|---|---|---|---|---|---|---|
| 30-500 | 300-500 | 350 | 30-100 | 30 | 91.0% | 0.99 | 0.96 | IT 0-10 30/100-277 P67 U A12 |
| 55-1050 | 550-1050 | 700 | 17-54 | 30 | 90.0% | 0.99 | 0.96 | IT 0-10 30/100-277 P67 U A12 |
|
