Not Recommended for New Design.
- Inventronics Patented Metal Case (Patent NO.: 202030323060.3)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Potentiometer (Sx models)
- Adjustable Output Current (AOC) with Programmability (Dx models)
- 1-10V/10V PWM/3-Timer-Modes Dimmable (Only Dx models)
- Dim-to-Low-Voltage (DTLV) with Standby Power ≤ 0.5W (Function Selectable)
- Input Surge Protection: DM 6kV, CM 6kV
- All-Around Protection: OVP, SCP, OTP
- IP65 and UL Dry/Damp/Wet Location
- SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
98,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x H)
ø5.12 x 2.44
Millimeters (L x H)
ø130 x 62
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 3000 – 4200 mA | 3300 mA | 90 ~ 305 Vac 127 ~ 250 Vdc |
34 – 54 Vdc | 160 W | EUR-160S420DG |
| 3000 – 4200 mA | 3300 mA | 34 – 54 Vdc | EUR-160S420SG |
|
