- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Output Lumen Compensation
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP66/IP67
- SELV Output
- Suitable for Luminaires with Protection Class I and II
- 5 Year Warranty
Life Time
106,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.54 x 2.36 x 1.44
Millimeters (L x W x H)
166 x 60 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 530 – 700 mA | 530mA | 90 ~ 305 Vac 127 – 300 Vdc |
107 – 284 Vdc | 150 W | EUM-150S070DE |
| 700 – 1050 mA | 700mA | 72 – 214 Vdc | EUM-150S105DE | ||
| 1050 – 1500mA | 1050mA | 50-143Vdc | EUM-150S150DE | ||
| 1400 – 2100mA | 1400mA | 36-107Vdc | EUM-150S210DE | ||
| 2800 – 4200mA | 3150mA | 18 ~ 54 Vdc | EUM-150S420DE |
|
