• Compact Metal Case with Excellent Thermal Performance
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Programmability
  • Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • Class 2 & SELV Output
  • Suitable for Luminaires with Protection Class I
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

114,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
5.35 x 2.36 x 1.44

Millimeters (L x W x H)
136 x 60 x 36.5

Certifications

Adjustable
Output
Current
Range(mA)		 Full-Power
Current
Range(mA)		 Default
Output
Current(mA)		 Output
Voltage
Range(Vdc)		 Max.
Output
Power(W)		 Typical
Efficiency		 Typical
Power Factor
120Vac		 Typical
Power Factor
220Vac		 Model Number
35-530 350-530 530 94-286 100 94.0% 0.99 0.96 EUM-100S280DE
70-1050 700-1050 700 48-143 100 93.0% 0.99 0.96 EUM-100S280DE
105-1500 1050-1500 1050 34-95 100 93.0% 0.99 0.96 EUM-100S280DE
175-2800 1750-2800 2100 17-54 96 92.0% 0.99 0.96 EUM-100S280DE
