FEATURES
- Ultra High Efficiency (Up to 94%)
- Full Power at Wide Output Current Range (Constant Power)
- 0-5V/0-10V/PWM/Timer Dimmable
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67 and UL Dry / Damp / Wet Location
- SELV Output
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) location
- UL Type TL (Temperature Limited)
- 7 Year Warranty
Life Time
109,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.35 x 2.66 x 1.56
Millimeters (L x W x H)
212 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA |
90 ~ 305 Vac |
114 – 343 Vdc |
240 W |
EUG-240S105DT |
| 1400 – 2100 mA | 1400 mA | 57 – 171 Vdc | EUG-240S210DT | ||
| 2800 – 4200 mA | 4200 mA | 29 – 86 Vdc | EUG-240S420DT | ||
| 4450 – 6700 mA | 6700 mA | 18 – 54 Vdc | EUG-240S670DT |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
