FEATURES
- Innovative Design with No Electrolytic Capacitors
- Ultra Long Lifetime: Greater than 100,000 hrs at 85°C Case Temperature
- Full Power at Wide Output Current Range (Constant Power)
- Thermal Sensing and Protection for LED Module
- 0–10V / PWM / Timer Dimmable (3 Timer Modes)
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12Vdc, 200mA
- Output Lumen Compensation
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67 and UL Dry / Damp / Wet Location
- Class 2 & SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 10 Year Warranty
Life Time
100,000 hours @ Case Temperature 85°C
Dimensions
Inches (L x W x H)
7.09 x 2.66 x 1.44
Millimeters (L x W x H)
180 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA |
90 ~ 305 Vac |
74 – 213 Vdc |
96 W |
EUD-096S070DTL |
| 700 – 1050 mA | 700 mA | 48 – 137 Vdc | EUD-096S105DTL | ||
| 1400 – 2100 mA | 2100 mA | 24 – 69 Vdc | EUD-096S210DTL | ||
| 1750 – 2150 mA | 2100 mA | 24 – 55 Vdc | EUD-096S215DTL | ||
| 2450 – 3500 mA | 2800 mA | 14 – 39 Vdc | EUD-096S350DTL |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
