FEATURES
- Ultra High Efficiency (Up to 93.5%)
- Ultra High Input Voltage (249~528Vac)
- Constant Voltage Output
- Input Surge Protection: DM 6kV, CM 10kV
- IP67 and UL Dry / Damp / Wet Location
- UL Class P & SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
93,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.82 x 3.86 x 1.76
Millimeters (L x W x H)
224 x 98 x 44.8
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 24 Vdc | 249 ~ 528 Vac | 0 ~ 13.4 A | 320 W | ESV-320S024ST |
| 36 Vdc | 0 ~ 8.9 A | ESV-320S036ST | ||
| 48 Vdc | 0 ~ 6.7 A | ESV-320S048ST | ||
| 54 Vdc | 0 ~ 6.0 A | ESV-320S054ST |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
