FEATURES
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 and D4i Certified
- 3-Timer-Modes Dimmable
- Dim-to-Off with Low Standby Power
- Always-on Auxiliary Power: 24Vdc, 125mA, 3W (Transient Peak Power up to 10W)
- Integrated 16Vdc Bus Power Supply based on DALI-2
- Integrated Power Monitoring with High Accuracy up to ±1%
- Output Lumen Compensation
- End-of-Life Indicator
- Thermal Sensing and Protection for LED Module
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.34 × 3.01 × 1.52
Millimeters (L x W x H)
161 × 76.5 × 38.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA |
249 – 528 Vac |
72 – 214 Vdc |
150 W |
ESM-150S105BG |
| 1050 – 1500 mA | 1050 mA | 50 – 143 Vdc | ESM-150S150BG | ||
| 1400 – 2100 mA | 1400 mA | 36 – 107 Vdc | ESM-150S210BG | ||
| 2800 – 4200 mA | 3150 mA | 18 – 54 Vdc | ESM-150S420BG |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated 3-3-2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated December 2020)
|
