FEATURES

  • Ultra High Efficiency (Up to 91.5%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Programmability
  • Isolated 0-10V / 10V PWM / Resistor Dimmable
  • Adjustable Dimming Curve
  • Dim-to-Low-Voltage (DTLV) with Standby Power ≤ 0.5W
  • Fade-Time Adjustable
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP65 and UL Dry/Damp Location
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

103,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
14.65 × 1.71 × 1.24

Millimeters (L x W x H)
372 × 43.5 × 31.5





Certifications

Full-Power Current Range  Default Output Current  Input Voltage Range  Output Voltage Range  Max. Output Power  Model Number
6100mA – 6900mA 6100 mA 90-305Vac
127-300Vdc		 34 – 54Vdc 330W SUM-330S690HF
