FEATURES
- Non-Isolated Design with Low Residual Output Voltage < 2kV
- No Afterglow
- Ultra High Efficiency (Up to 97.0%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/10V PWM/Resistor/3-Timer-Modes Dimmable
- Dim-to-Off with Standby Power ≤ 0.5W
- Maximum Dimming Level with 9V or 10V Selectable
- Fade-time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OVP, SCP, OTP
- Suitable for Luminaires with Protection Class I
- 5 Years Warranty
Life Time
102,000 hours @ 70C
Dimensions
17.80 in × 1.59 in × 1.57 in
452mm × 40.5mm × 40mm
Certifications
| Adjustable Output Current Range(mA) | Full-Power Current Range(mA) | Default Output Current(mA) | Output Voltage Range(Vdc) | Max. Output Power(W) | Typical Efficiency | Typical Power Factor | Model Number |
| 73-1400 | 730-1400 | 1400 | 150-550 | 400 | 97.0% | 0.97 | NEL-400S140MP |
