FEATURES

  • Flicker-free
  • Full power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Potentiometer
  • Non-dimming control
  • Input Surge Protection: DM 4kV, CM 6kV
  • High Reliability & Long Lifetime: 116,000 hrs. at 70C
  • Case Temperature
  • Suitable for Built-in Use and Class I Luminaires
  • IP54 and UL Dry / Damp Location
  • Class 2 & SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

116,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x H)
ø3.54 x 1.81

Millimeters (L x H)
ø90 x 46

Certifications

Independent Gear Logo

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 1050 mA 90 ~ 305 Vac
127 ~ 250 Vdc		 34 – 54 Vdc 40 W LUR-040S105ST
1000 – 1500 mA 1400 mA 24 – 40 Vdc LUR-040S150ST
File Name
LED Driver Installation Guideline (Updated September 2018)
Download
