FEATURES

  • High Efficiency (Up to 92.5%)
  • Constant Voltage Output
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: OVP, OCP, SCP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

95,200 hours @ Case Temperature 60°C

Dimensions

Inches (L x W x H)
7.83 x 2.66 x 1.56

Millimeters (L x W x H)
199 x 67.5 x 39.5

Certifications

Output Voltage Input Voltage Range Output Current Range Max. Output Power Model Number
12 V 90 ~ 305 Vac
127 ~ 250 Vdc		 0 ~ 15 A 180 W EUV-200S012SV
24 V 0 ~ 8.33 A 200 W EUV-200S024SV
36 V 0 ~ 5.56 A EUV-200S036SV
42 V 0 ~ 4.76 A EUV-200S042SV
48 V 0 ~ 4.17 A EUV-200S048SV
54 V 0 ~ 3.7 A EUV-200S054SV
File Name
LED Driver Installation Guideline (Updated September 2018)
Download
