FEATURES

  • High Efficiency (Up to 92.5%)
  • Constant Voltage Output
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: OVP, OCP, SCP, OTP
  • IP67 and UL Dry / Damp / Wet Location
  • SELV
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

95,200 hours @ Case Temperature 60°C

Dimensions

Inches (L x W x H)
7.83 x 2.66 x 1.56

Millimeters (L x W x H)
199 x 67.5 x 39.5

Certifications

Output Voltage Input Voltage Range Output Current Range Max. Output Power Model Number
12 V 90 ~ 305 Vac 0 ~ 15.00 A 180 W EUV-200S012ST
24 V 0 ~ 8.33 A 200 W EUV-200S024ST
36 V 0 ~ 5.56 A EUV-200S036ST
42 V 0 ~ 4.76 A EUV-200S042ST
48 V 0 ~ 4.17 A EUV-200S048ST
54 V 0 ~ 3.70 A EUV-200S054ST
File Name
LED Driver Installation Installation Guideline (Updated September 2018)
Download
