Not Recommended for New Design.
We Recommend our EBV-100SxxxSV as a Replacement.
- Ultra High Efficiency (Up to 90%)
- High Power Factor (0.99 Typical)
- Constant Voltage Output
- Input Surge Protection: DM 4kV, CM 6kV
- All-Round Protection: OVP, OCP, SCP, OTP
- IP67 and UL Dry / Damp / Wet Location
- SELV Output
- 5 Year Warranty
Life Time
56,600 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
6.85 x 2.66 x 1.44
Millimeters (L x W x H)
174 x 67.5 x 36.5
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 24 V |
90 ~ 305 Vac |
0 ~ 4 A |
96 W |
EUV-096S024ST |
| 36 V | 0 ~ 2.66 A | EUV-096S036ST | ||
| 48 V | 0 ~ 2 A | EUV-096S048ST | ||
| 54 V | 0 ~ 1.77 A | EUV-096S054ST |
|
