FEATURES
- Ultra High Efficiency (Up to 94%)
- Full Power at Wide Output Current Range (Constant Power)
- Thermal Sensing and Protection for LED Module
- DALI / 3-Timer-Modes Dimmable
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12 Vdc, 200 mA
- Output Lumen Compensation
- Input Surge Protection: DM 6 kV, CM 10 kV
- All-Around Protection: OVP, SCP, OTP
- IP67 and UL Dry / Damp / Wet Location
- SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 7 Year Warranty
Life Time
97,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.86 x 3.86 x 1.77
Millimeters (L x W x H)
225 x 98 x 44.8
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 1050 – 1500 mA | 1400 mA |
90 ~ 305 Vac |
107 – 305 Vdc |
320 W |
EUD-320S150BT |
| 1540 – 2200 mA | 2100 mA | 73 – 208 Vdc | EUD-320S220BT | ||
| 2240 – 3200 mA | 2800 mA | 50 – 143 Vdc | EUD-320S320BT | ||
| 3220 – 4600 mA | 4200 mA | 35 – 100 Vdc | EUD-320S460BT | ||
| 4690 – 6700 mA | 6700 mA | 24 – 68 Vdc | EUD-320S670BT |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Inventronics DALI Driver Programmer Manual Instruction (Updated November 2016)
|
|
Programming Interface for DALI-Program (Updated May 2015)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
