FEATURES

  • Innovative Design with No Electrolytic Capacitors
  • Ultra Long Lifetime: Greater than 100,000 hrs at 85°C Case Temperature
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0–10V / PWM / Timer Dimmable (3 Timer Modes)
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67 and UL Dry / Damp / Wet Location
  • SELV Output
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 10 Year Warranty
Download Data Sheet
Order Here

Life Time

100,000 hours @ Case Temperature 85°C

Dimensions

Inches (L x W x H)
8.86 x 2.66 x 1.56

Millimeters (L x W x H)
225 x 67.5 x 39.7

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 1050 mA

90 ~ 305 Vac
127 ~ 300 Vdc

 114 – 343 Vdc

240 W

 EUD-240S105DTL
1400 – 2100 mA 1400 mA 57 – 171 Vdc EUD-240S210DTL
2800 – 4200 mA 4200 mA 29 – 86 Vdc EUD-240S420DTL
4450 – 6700 mA 6700 mA 18 – 54 Vdc EUD-240S670DTL
