FEATURES

  • Ultra High Efficiency (Up to 94.5%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak Current up to 400mA)
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67 and UL Dry / Damp / Wet Location
  • SELV Output
  • TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

108,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.27 x 2.66 x 1.56

Millimeters (L x W x H)
210 x 67.5 x 39.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 700 mA

90 ~ 305 Vac
100 ~ 300 Vdc

 95 – 286 Vdc

200 W

 EUD-200S105DTA
1400 – 2100 mA 1400 mA 48 – 143 Vdc EUD-200S210DTA
2450 – 3500 mA 2800 mA 29 – 82 Vdc EUD-200S350DTA
3850 – 5600 mA 4900 mA 18 – 52 Vdc EUD-200S560DTA
