This product has been discontinued. We recommend the EUM-150SxxxBT as a replacement.
FEATURES
- Ultra High Efficiency (Up to 94%)
- Full Power at Wide Output Current Range (Constant Power)
- Thermal Sensing and Protection for LED Module
- 0-10V/PWM/3-Timer-Modes Dimmable (DTA models)
- DALI Dimming Control (BTA models)
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak Current up to 400mA)
- Output Lumen Compensation ( DTA models)
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67 and UL Dry/Damp/Wet Location
- SELV Output
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- 7 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.03 x 2.66 x 1.56
Millimeters (L x W x H)
204 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA | 90 ~ 305 Vac 100 ~ 300 Vdc |
75 – 214 Vdc | 150 W | EUD-150S105BTA |
| 1400 – 2100 mA | 1400 mA | 38 – 107 Vdc | EUD-150S210BTA | ||
| 2450 – 3500 mA | 3150 mA | 22 – 61 Vdc | EUD-150S350BTA | ||
| 3850 – 5600 mA | 4200 mA | 14 – 39 Vdc | EUD-150S560BTA |
|
