FEATURES
- Ultra High Efficiency (Up to 93%)
- Full Power at Wide Output Current Range (Constant Power)
- Thermal Sensing and Protection for LED Module
- 0–10V / PWM / 3‑Timer‑Modes Dimmable
- Dim‑to‑Off with Standby Power ≤ 0.5 W
- Always‑on Auxiliary Power: 12Vdc, 200mA (Transient peak current up to 400mA)
- Output Lumen Compensation
- Input Surge Protection: DM 6kV, CM 10kV
- All‑Around Protection: OVP, SCP, OTP
- IP67
- SELV Output
- 7 Year Warranty
Life Time
104,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
7.09 x 2.66 x 1.44
Millimeters (L x W x H)
180 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA |
90 ~ 305 Vac |
74 – 213 Vdc |
96 W |
EUD-096S070DVA |
| 700 – 1050 mA | 700 mA | 48 – 137 Vdc | EUD-096S105DVA | ||
| 1400 – 2100 mA | 2100 mA | 24 – 69 Vdc | EUD-096S210DVA | ||
| 2450 – 3500 mA | 2800 mA | 14 – 39 Vdc | EUD-096S350DVA |
|
