FEATURES

  • Low THD, 10% Max up to 240 Vac
  • Compact Metal Case with Excellent Thermal Performance
  • Input Surge Protection: DM 4 kV, CM 6 kV
  • High Reliability & Long Lifetime: 80,000 hrs at 70°C Case Temperature
  • Suitable for Built-in Use and Class I Luminaires
  • IUVP & IOVP
  • IP66 and UL Dry/Damp Location
  • Class 2 & SELV Output
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

80,000 hours @ Case Temperature 75°C

Dimensions

Inches (L x W x H)
3.15 x 2.52 x 1.26

Millimeters (L x W x H)
80 x 64 x 32

Certifications

TUV SUD Certification Logo

Output Current Input Voltage Range Output Voltage Range Max. Output  Power Model Number
500 mA 90 ~ 305 Vac 32 – 64 Vdc 32W EUC-035S070STM0004
700 mA 25 – 47 Vdc 33W EUC-035S105STM0007
860 mA 20 – 41 Vdc 35W EUC-035S105STM0004
1050 mA 18 – 33 Vdc EUC-035S105STM
Note: Models listed are not all-inclusive. For additional models please contact our sales department.
