FEATURES
- Ultra High Efficiency (Up to 93.5%)
- Ultra High Input Voltage (249~528Vac)
- Constant Voltage Output
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OCP, SCP, OTP, OVP
- IUVP and IOVP
- IP67
- SELV Output
- 5 Year Warranty
Life Time
117,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
9.84 x 5.67 x 1.19
Millimeters (L x W x H)
250 x 144 x 48.5
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 48 Vdc | 249 ~ 528 Vac
352 ~ 500 Vdc |
0 ~ 12.5 A | 600 W | ESV-600S048SV |
| 54 Vdc | 0 ~ 11.2 A | ESV-600S054SV |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
