FEATURES

  • Ultra High Efficiency (Up to 93.5%)
  • Ultra High Input Voltage (249~528Vac)
  • Constant Voltage Output
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OCP, OVP, SCP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

93,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.82 x 3.86 x 1.76

Millimeters (L x W x H)
224 x 98 x 44.8

Certifications

Output Voltage Input Voltage Range Output Current Range Max. Output Power Model Number
24 Vdc 249 ~ 528 Vac

 0 ~ 13.4 A 320 W

 ESV-320S024SV
36 Vdc 0 ~ 8.9  A ESV-320S036SV
48 Vdc 0 ~ 6.7 A ESV-320S048SV
54 Vdc 0 ~ 6.0 A ESV-320S054SV
File Name
LED Driver Installation Instructions (Updated March 2015)
Download
LED Driver Installation Guideline (Updated September 2018)
Download
