- High Efficiency (up to 91%)
- Constant Voltage Output
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OCP, OVP, OTP, SCP
- IP67
- SELV Output
- 5 Year Warranty
Life Time
99,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.46 x 1.57 x 0.98
Millimeters (L x W x H)
164 x 40.0 x 25.0
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 24 V |
176 ~ 305 Vac |
0 ~ 3.0 A |
60 W |
EBV-072S024SVF |
| 36 V | 0 ~ 2.0 A | EBV-072S036SVF | ||
| 48 V | 0 ~ 1.5 A | EBV-072S048SVF |
|
File Name
|
|---|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
LED Driver Installation Instructions (Updated March 2015)
|
